Digital Multi-Chek® Celsius

Overview

Digital Multi-Chek® Celsius

Meets ASTM D3321-12 Standard test method for field test determination for the freezing point of aqueous engine coolants.
Digital instrument for testing automotive fluids
One accurate tester performs three critical tests. Test coolant, battery and windshield fluids.
Why take chances? For precise reading of coolant concentration, hydrometers just don't measure up. The Reichert Digital Multi-Chek® accurately and effectively tests coolant - both ethylene and propylene glycol - as well as battery charge and windshield fluid. The instrument provides an accurate digital tool for your convenience, your customers' peace of mind, and increased profits for your shop.
The Reichert Digital Multi-Chek® is economical to operate, providing 10,000+ measurements on two AAA batteries.

NO PHOTO

Specifications

Technical Specifications:

Catalog Number	13940015
Reading Scales	EG=Freeze point, ethylene glycol antifreeze PG=Freeze point, propylene glycol antifreeze SG=Specific gravity, battery acid WW=Freeze point, windshield washer solution
Reading Ranges	EG 0°C thru -57°C, Accuracy +/- 0.3°C PG 0°C thru -51°C, Accuracy +/- 0.3°C Battery - 1.000 - 1.463 SG, Accuracy +/- 0.003 SG Windshield Washer 0°C thru -54°C, Accuracy +/- 1°C
Automatic Temperature Compensation	20°C
Calibration	Distilled Water
Prism	Glass
Illumination	589nm LED
Ratings and Compliance	IP65 Dustproof/Water Resistant, CE, RoHS, and WEEE Compliant
Dimensions	54 x 27 x 100 mm / 2.1 x 1.1 x 3.9 inches
Weight	100 grams / 3.5 ounces
Power	2 AAA Batteries, included
Battery Life	10,000 readings, Auto-Off Sleep Mode
Warranty	One year against manufacturing defects. Evidence of tampering voids warranty.

Application

Digital Multi-Chek® Celsius

Key Features

Coolant Tester
- Coolant tester tests engine coolant freeze point EG and PG concentration.
- Automatic temperature compensation (ATC) provides immediate, accurate, direct readings at ASTM D3321 standards of +/- 1°F and +/-0.55°C.
Battery Fluid Tester
- Fast and easy test of battery electrolyte, specific gravity, and condition.
Windshield
- Push button safety test for water fluid freeze point.
Choose between two instruments:
- Measure in degrees Fahrenheit
- Measure in degrees Celsius

Leave the science to Reichert.

With the simple push of a button, the Reichert Digital Multi-Chek®, the world's smallest handheld tester, will quickly and accurately provide you and your customer with ASTM standard readings for critical coolant, battery and windshield fluids.

Improper concentrations (high and low) of glycol coolants/anti-freeze will result in inadequate freeze protection and general corrosion of materials in contact with glycol. Glycol is designed to work at its best efficiency when properly mixed at its correct concentration level. Under-concentrated glycol will result in frozen/burst pipes and engine blocks. With batteries, an improper electrolyte level will result in a dead battery cell. Improper concentrations of windshield wiper fluid could result in hazardous slushing and washer freeze-ups.

The Reichert Digital Multi-Chek®...
the fast, accurate, state-of-the-art alternative to hydrometers and test strips.

Just how inaccurate are hydrometers?

According to ASTM method D1124. the BEST accuracy that is achievable with a laboratory-tested hydrometer in a controlled environment is 0±8° F. But, the field hydrometers commonly used in the service industry are not certified and have been tested and found to be inaccurate by as much as 0±23° F.

Just how accurate is Multi-Chek?

The Reichert Digital Multi-Chek® meets ASTM D3321 refractometer method standards for accuracy of ±1° F and ±0.55°C.
